Trench Struts

The Trench Struts feature innovative clawed base and head plates for superior trench lining grip and collapse prevention. These premium struts combine precision thread-rolled construction with heavy-duty 60.3mm outer tube diameter and reinforced 75mm base plates, delivering unmatched safety and reliability for professional trenching applications.

Read full description

Select from product options

Product

Code

Weight

Product Weight (kg) Width (mm) Length (mm) Height (mm)
Trench Struts Size 1 6.58 - - -
Trench Struts Size 2 8.62 - - -
Trench Struts Size 0 4.99 - - -
Trench Struts Size 3 11.69 - - -

The Trench Struts deliver exceptional safety and reliability for demanding excavation applications, manufactured to strict BS4074:2004 standards. Engineered with innovative features and robust construction, these struts set the industry standard for trench support systems.

Key Specifications:

- 3-tonne safe working load (SWL) at all lengths

- 60.3mm diameter outer tube

- 48.3mm diameter inner tube

- 75mm x 75mm x 6mm base and head plates

- Dual nail hole clawed design

- Available in four versatile sizes

Professional Features:

- Thread-rolled construction for maximum strength

- Clawed base and head plates for superior grip

- Advanced collapse prevention system

- Zero material loss design

- BS4074:2004 certified

- Complete trench lining security

Discover our comprehensive range of professional-grade Props & Struts, including Adjustable Push-Pull Props

Goods can be picked up from the nearest convenient location or delivered by our fleet. Prices are on application and tiered based on the distance and order volume between the branch the goods are transported from and the delivery site:

1 - 10 miles

11 - 25 miles

26 - 40 miles

40 miles+

Find your local branch

To find out if the product you're searching for is stocked nearby, enter your site's postcode, and then give us a call to discuss your requirements.
