More about Ranger Stair

The RangerTM Stair is a range of self-contained, pre-assembled Aluminium Stair Units, flat packed, which automatically adjust to a wide range of lift heights, making them ideal for use in Tube and Fitting Scaffolds along with other applications. The RangerTM Stair is fully compliant with BS EN12811 for all possible configurations.

KEY FEATURES & BENEFITS

Ease Of Use: Its aluminium construction makes it outstandingly light, easy to handle, and transport. Not only does it boast a comfortable 680mm clear width, its integral double handrails adapt automatically to the right height, whatever the angle of the stair. The handrail folds flat for transport and is simply unfolded for use, reinforced vertical posts are inserted into special sockets and secured with hammer wedges.

Easy To Install: Ranger Stair is pre-assembled, all that is necessary is to unfold the stair unit, hang it from a Scaffold Tube and attach the Guardrails, leading to minimum erection time on the site. The stairs and guardrails are erected without spanner work. Designed with the tube and fittings scaffolder in mind, the Ranger Stair can be used to build a totally compliant stair tower using existing stocks of tube, fittings and boards, keeping capital expenditure to a minimum.

A Versatile and Flexible System: Ranger Stair can also be used equally well within System Scaffolds and has wider applications outside scaffolding use. Ranger Stair’s 5 models span from 0.6m to 3.5m lift heights and each model is adjustable for lift height over a wide range, making Ranger Stair supremely versatile, especially within the Tube and Fitting scaffold structures. While system stairs can only accommodate fixed lift heights, Ranger Stair automatically takes care of variable or floor-level lifts, without the need to construct awkward angled run-offs or step-ups.

Safe: Safety is assured when using Ranger Stair. Deep section stringers ensure great rigidity in use. Wide, perforated non-slip treads are provided which are very strong, each tread being able to support two average-sized persons (1.5kN). Integral locking devices are provided to secure the stair at the desired angle, while standard-fit scaffold hooks have neat gravity locks. Ranger Stair is fully compliant with Class B of BS EN 12811 in all permissible configurations.

APPLICATIONS

Ranger Stair is very versatile and can be used for access on pitched roofs, inclined slopes or cuttings. Interchangeable end fittings for Scaffold Tubes, system transoms, concrete slabs, timber joists and formwork decking are all available. Supplied as a pre-assembled flight with or without guardrails and as standard with a pair of scaffold hooks. Interchangeable hooks or hanger brackets are available for different applications.

GET IN TOUCH WITH US

For more information on Ranger Stair, Contact Your Local Branch for expert advice and in depth product information. We're happy to help!
