Jayville Standard Drag Box

The Drag Box acts as a shield to protect users in self supporting soil. It is designed to withstand up to 25kN/m2. Installation requires the ‘Excavate and Drag’ technique, the box is placed in a pre-dug trench and moved after each instalment of pipe.

Read full description

Select from product options

Product

Code

Weight

Product Weight (kg) Width (mm) Length (mm) Height (mm)
Jayville Standard Drag Box 5m 3020 700 - 3500 5000 2500
Jayville Standard Drag Box 7m 4550 700 - 3500 7000 2000

The Drag Box acts as a shield to protect users in self supporting soil. It is designed to withstand up to 25kN/m2. Installation requires the ‘Excavate and Drag’ technique, the box is placed in a pre-dug trench and moved after each instalment of pipe.

  • Lifting points for safe slinging

  • For use in self-supporting soil

  • Standard Drag Box 4 Struts

  • Edge Safe Systems Available

  • Ladder Access System Available

  • Can be used in conjunction with Manhole Boxes

Download brochure

Goods can be picked up from the nearest convenient location or delivered by our fleet. Prices are on application and tiered based on the distance and order volume between the branch the goods are transported from and the delivery site:

1 - 10 miles

11 - 25 miles

26 - 40 miles

40 miles+

Find your local branch

To find out if the product you're searching for is stocked nearby, enter your site's postcode, and then give us a call to discuss your requirements.
