The Fall-Pac System comprises a high quality inner and outer bag containing polystyrene fill which is designed to absorb the energy of a fall by personnel. Easily installed and placed within a house structure Fall Pac arrests falls up to 2.8m
17% increase in size from previous bags
Net reduction of cost per sq metre
Higher profile bag 644mm giving more protection
40% Higher impact absorbent tested to 2.8m
High standard of Material giving 50% longer life
Flame retardant as Standard, No Extra Charges
Self-supporting not requiring containment within walls
Close pack design requiring no “Foot Test”
Environmental clearance of existing stocks
Outer Bag repels water
The Fall-Pac construction consists of a tubular polypropylene outer casing fitted with interlocking fastening devices containing treated impact absorbing material. Each bag weighs approximately 6 kilos and can be installed quickly and simply in applications throughout the industry.
Fall Pac Cushion System is also suitable for use in vehicle applications where there is a risk of fall from a load platform or other elevated surface.
Coverage & Performance
Each Fall-Pac has a length of 2.5m and a diameter of 0.644m, this gives a true surface coverage of 1.61 sq. metres making installation quick and large areas easy to cover. Half-Pac’s (length 1.25mtrs) are available to optimise coverage. Due to the unique design each Fall-Pac maintains its high impact absorbency as a single unit, this results in a consistent high performance installed system.
Fire Testing
The Fall-Pac modular impact cushioning system has been fully tested for resistance to flammability using British standard ignition sourcesadapted from BS 5852.
Ignition Source 0 = Cigarette
Ignition Source 1 = Match
Ignition Source 2 = Calorific value of five rolled up sheets of newspaper
Surface Coating
The main body of the Fall-Pac is treated with a special surface coating which gives many advantages including reduction of water ingress, increased impact absorbency and increased anti-soiling properties.
